Flat and elegant with firm edges, the Sheer CFX® range helps provide the finishing touch to any project. The faceplates are firmly held in place to the back frame with a patented 4 point clipping system, concealing the fixings for a seamless finish.

• Superb finishes, including four shades of Bronze
• Choice of complementary switch insert finishes
• Concealed fixing (CFX)
• Painted plates available
• Grid & EuroFix options also available
• Ultra-fast USB charging technology

Brand	Hamilton
Finish	Bright Chrome, Polished Brass, Satin Brass, Stainless
Insert Colour	Black, White
Dimensions (H x W x L)	86 x 86 x 1.5mm plate + 3mm gasket
Fixing Hole Centres	60.3mm
Minimum Wall Box Depth	35mm
Switched Poles	Single
Current Rating	10 Amp
Voltage	220/250V
Maximum Load	10 Amp (6 Amp inductive)
Mains Frequency	50Hz
IP Rating	IP2XD
Contact Gap Minimum	3mm
Terminal Capacity 1	3x1mm
Terminal Capacity 2	2×1.5mm
Terminal Capacity 3	1×2.5mm
Earth Terminal Capacity 1
Earth Terminal Capacity 2	4 x 1.5mm
Earth Terminal Capacity 3	3 x 2.5mm
Earth Terminal Capacity 4	1 x 4mm multi-shared
Earth Terminal Capacity 5	1 x 6mm
Recommended Location	Internal Use Only
Standard Approval	BS EN 60669-2-3
